Application Types LC-MS, CAD & ELSD

Part number: 10-2015

Status Retired i

Integrated compressor No

Infinity NM18L Nitrogen Generators

The Infinity NM18L nitrogen generator has been engineered to cater for the requirements of LC-MS, sample evaporators, and NMR applications when connected to an external source of air.

View active replacement

Features

  • Delivers nitrogen at up to 18L/min
  • This generator can supply multiple LC-MS instruments
  • 24/7 operation at optimum performance if required
  • Highly economical source of nitrogen with low lifetime running costs
  • Few moving parts means little maintenance and ensures long life of the generator
  • Gas is supplied on demand so generator works to your schedule
  • Minimal set-up required
  • Completely silent in operation
  • 12 month comprehensive on-site warranty

Gas

Gas Type: Nitrogen

Min Gas Flow: 0L/min

Max Gas Flow: 18L/min

Max Output Pressure: 100psi/6.9bar

Site & Installation

Min Inlet Pressure: 120psi/8.3bar

Max Inlet Pressure: 145psi/10bar

Min Air Inlet Flow: 50

Min Inlet Air Quality: 1.4.1

Start Up Time: 60 mins

Power Consumption: none

Voltage: N/A

Frequency: N/A

Current: N/A

Heat output: none

Max Operating Temp: 30°C / 86°F

Particles: <0.01 ‎μm

Phthalates: none

Suspended Liquids: none

Accreditations: CE

Dimensions & weight

Infinty NM18L Dimensions 01

Size (HxWxD) mm: 760 x 250 x 160 mm

Size (HxWxD) Inches: 29.9 x 9.8 x 6.3 inches

Generator Weight: 18kg / 39.6lbs
